4x2 Models, No GCM Increase for 2.0L Bi-Turbo models
GVM Upgrade Details
GVM: Increased from 3150kg to 3800kg
GCM: Increased from 6250kg to 7200kg
Front Axle Capacity: Increased from 1470kg to 1680kg
Rear Axle Capacity: Increased from 1770kg to 2120kg
Special Conditions
Indicators
This vehicle requires Category 6 indicators due to a change from passenger to commercial classification. These are installed on the front guards as part of the upgrade.
Reverse Lights
Suspension lift raises the reverse lights above ADR limits. Compliant reverse lights are installed and factory reverse lights are disabled.
Wheels & Tyres
Factory tyres meet the required specifications for this GVM upgrade.
Kit Contents
Lovells heavy duty front and rear springs
Lovells Platinum Series Remote Reservoir
shock absorbers
Required fittings and components
Certification & Compliance paperwork
Category 6 front guard indicator kit
ADR-compliant reverse light relocation kit
Compliance
This is an ADR-compliant and federally approved GVM upgrade. For federal approval, the kit must be installed prior to first registration. This pathway suits new vehicles and allows for a certified GVM & GCM increase from day one.
For registered vehicles, the upgrade must be certified by an Authorised Inspection Station. The vehicle must be in roadworthy condition and presented for inspection following installation. Our pricing covers the full process, including the modification application, inspection, and final approval permit.
Note: The Western Australian Government has indicated that post-registration GCM upgrades may be approved in future. However, no implementation date has been confirmed. Lovells continues to work closely with the Department of Transport to progress this approval.
General Usage
This upgrade is designed for vehicles carrying increased constant loads. Ride quality may be firmer when unladen. The GVM upgrade kit must be installed by Ultimate 4WD, an approved Lovells GVM certifier, to ensure full compliance and a legally recognised upgrade.
